Text By Mike McGlothlin

Let's face it, when winter strikes no one experiences cold-start issues quite like 6.0L Powerstroke owners. Thanks to this mill's hydraulically activated fuel injection system, relying on cold engine oil to actuate the injectors properly at startup can be a tall order in frigid weather. And when you factor the phenomenon known as "stiction" into the equation, the chances of your '03 to '07 Ford Super Duty firing on all eight cylinders is nearly impossible in such conditions. Over the years, we've seen several oil additives come to market with the goal of solving stiction issues, and this month we're putting the latest product through its paces: Archoil AR9100.

Stiction: Cause and Effect

Stiction is the static friction that needs to be overcome for one surface in contact with another to move. Stiction, in this case, is often the result of oil coking and carbon buildup inside the spool valve -- the vital component that allows high-pressure oil (required to actuate the fuel side of the Power Stroke HEUI injector) to enter the injector. This gummy, oily residue hampers oil flow through the valve, and when the spool valve cannot open and close as precisely as it needs to, stiction is at work. It leads to inconsistent fuel quantities leaving the injector nozzle, and poor fuel atomization occurring in-cylinder. Common symptoms are hard starting, rough idling, and oftentimes a truck that's smoking while it warms up in the driveway. If neglected long enough, stiction can cause irreparable spool valve bore wear, with expensive injector replacement being the only permanent solution.

Ford F-350 Before Treatment

Our cold weather candidate suffering from severe
stiction issues was this '05 Ford F-350 with 265,000
miles on the clock. With the original injectors needing to be replaced at 150,000 miles, the owner fully expected he would once again be replacing them when he brought the truck to Flynn's shop in Alexander, Illinois. To see how poorly the truck could handle cold starts, it was parked outside overnight, in 20-degree weather. Because stiction issues typically subside as the engine oil begins to warm (due to the oil thinning out), we performed a cylinder balance test within 30 seconds of starting the truck. The result: just four of eight cylinders were in good working order. This meant half of the engine's injectors were suffering from stiction.

Stiction Eliminated

TEST RESULT (AFTER 15 MILES)

First things first: The oil was drained and switched to a lower-viscosity oil (5W-40 synthetic Shell Rotella vs. 15W-40 conventional). Knowing that changing to a thinner-weight oil wouldn't alleviate the severe stiction problems with this truck, it would more or less be icing on the cake if the Archoil additive worked. After the truck's dipstick read half a quart shy of being full, we topped off our 16-ounce jug of Archoil. From there, the truck was started, idled for 30 minutes and then taken on a 15-mile drive.

"The next morning, following a 15-degree night during which the truck once again sat outside, it fired right off and idled smoothly. Seeing this F-350 go from a cold-blooded, rough-running basket case to a truck that ran as smooth as it did the day it left the dealership definitely made believers out of us.
ARCHOIL IS THE REAL DEAL."



The Science Behind

Archoil AR9100

Because Archoil's AR9100 additive is activated by friction, signs of stiction can be cured in just a small amount of drive time. It uses four complex organic esters to effectively liquefy the oil, carbon, varnish, and sludge deposits within the spool valve -- not to mention it cleans the rest of the injector and entire fluid system. This allows a Nanoborate (a proprietary protective superlubricant) solid boundary layer to chelate to the deposit-free host alloy -- helping reduce metal-to-metal contact (i.e., friction) within the spool valve.

The Benefits

  • Cleans out carbon, sludge, and varnish buildup (big problem in spool valves) by liquefying them
  • Reduces surface friction and fluid system wear
  • Reduces noise and vibration
  • Minimizes fluid oxidation (extends oil drain cycle)
  • Inhibits corrosion
  • Works with either mineral or synthetic oil
